產 品 詳 細 介 紹：
儀表管接頭 >> YZG6～16系列自控管路附件 >> YZG14-1 單頭短節•單頭加厚短節 Instrument pipe joint >> YZG6～16 series automatic control pipeline accessories >> YZG14-1 Single Head Short-circuit • Thick Single Head Short-circuit
Explain: This series collects all kinds of connection forms and structural couplings, nipples, nozzles, rotary couplings, thermowells and other products in the automatic control instrument pipeline system. It is an essential connecting piece in the pipeline with a wide range of varieties, specifications and applications. The short joint YZG14 series is essentially a pressure taking part. It is applicable to various measuring circuits, especially pressure, flow and liquid level.
YZG14-1 單頭短節•單頭加厚短節 YZG14-1 Single Head Short-circuit • Thick Single Head Short-circuit
ZG
D
d0
L
代號Code No.
ZG1/4"
14
8
50
YZG14-1-ZG1/4"-50
ZG3/8"
18
10
70
YZG14-1-ZG3/8"-70
ZG1/2"
22
15
70
YZG14-1-ZG1/2"-70
ZG3/4"
27
20
70
YZG14-1-ZG3/4"-70
ZG1"
34
27
100
YZG14-1-ZG1"-100
ZG1 1/2"
48
31
100
YZG14-1-ZG1 1/2"-100
ZG2"
60
45
120
YZG14-1-ZG2"-120
ZG1/4"
14
3
50
YZG14-1-ZG1/4"-50-J
ZG3/8"
18
5
70
YZG14-1-ZG3/8"-70-J
ZG1/2"
22
10
70
YZG14-1-ZG1/2"-70-J
ZG3/4"
27
15
70
YZG14-1-ZG3/4"-70-J
ZG1"
34
22
100
YZG14-1-ZG1"-100-J
ZG1 1/2"
48
28
100
YZG14-1-ZG1 1/2"-100-J
ZG2"
60
40
120
YZG14-1-ZG2"-120-J
可指定長度L定制生產 YZG14-1 單頭短節•單頭加厚短節多用于壓力取源部件，一頭焊在壓力點，一端用螺紋與一次閥連接。代號中注“J”者為加厚短節，用途與規格同單頭短節，只是使用在壓力等級高的場合。 YZG14-1 single-head short joint • single-head thickened short joint is mostly used for pressure source parts, one end is welded at the pressure point, and one end is connected with the primary valve with thread. Those marked with "J" in the code are thickened nipples. The purpose and specification are the same as single-head nipples. They are only used in occasions with high pressure rating.
※注：YZG14-1 單頭短節•單頭加厚短節Single Head Short-circuit • Thick Single Head Short-circuit如有改進，恕不另行通知，以產品實物為準。
